Description
The GD75188 is a monolithic quadruple line driver designed to interface data terminal equipment with data communication equipment in conformance with the specifications of ElAstandard RS-232C with a diode in series with each supply-voltage terminal as shown under typical applications. The device is characterized for operation from 0°C to 75°C
75188 Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | VCC- | Negative Supply Voltage |
| 2 | 1B | Input in 1B |
| 3 | 1Y | Output Pin 1Y |
| 4 | 2A | Input in 2A |
| 5 | 2B | Input in 2B |
| 6 | 2Y | Output Pin 2Y |
| 7 | GND | Ground pin |
| 8 | 3Y | Output Pin 3Y |
| 9 | 3A | Input in 3A |
| 10 | 3B | Input in 3B |
| 11 | 4Y | Output Pin 4Y |
| 12 | 4A | Input in 4A |
| 13 | 4B | Input in 4B |
| 14 | VCC+ | Positive Supply Voltage |
Features
- Meets Specifications of EIA RS-232C
- Designed to be Interchangeable with SN75188
- Current Limited Output .. 10mA Typical
- Power-Off Output Impedance … 3002 Min
- Slew Rate Control by Load Capacitor
- Flexible Supply Voltage Range
- Input Compatible with Most TTL and DTL Circuits.
